FRAMEAlloy Frame & Link
Virtual 4 link kinematic VLK
29x2.6 / Boost 148x12mm UDH
160mm travel / Bosch Gen4 / Integr. removable Battery
1.8" Headtube, Central Kickstand Mount
Integr. Cable
TRAVELFront: 160mm / Rear: 160mm
FORKRockShox Domain Air
15x110mm QR axle / 1.8" Tapered Steerer
Reb. Adj. / 2 Modes / Lockout / 160mm travel / E-Bike
REAR SHOCKFOX Float EVOL eRIDE Trunnion
3 modes / Lockout-Trail-Descend
DPS / Reb. Adj.
Travel 160mm / 205x60mm
REMOTE SYSTEMSCOTT TwinLoc 2 Technology
Suspension & Dropper Remote
3 modes
DRIVE UNITBosch Performance CX
EU: 25kmh / INT: 20mph
BATTERYPowerTube 750Wh
DISPLAYBosch LED Remote & Kiox 300
CHARGER4A Charger
REAR DERAILLEURShimano XT / 12 Speed
SHIFTERSShimano SL-M6100
CRANKSETFSA CK-745 165mm / 34T
CHAINGUIDEe*thirteen / e*spec Slider
CHAINRINGFSA WB604 / 34T / DM / Steel
CHAINShimano CN-M6100
CASSETTEShimano CS-M6100 / 10-51 T
BRAKESShimano BR-MT520 4 Piston
ROTORFront: SM-RT64 CL 203mm / Rear: RT-EM600 CL 203mm
HANDLEBARSyncros Hixon 2.0 / Alloy 6061D.B.
12mm rise / 9° / 780mm
Syncros Pro lock-on grips
H'STEMSyncros AM2.0 / 6061 Alloy
31.8mm / 4° / 1 1/8"
SEATPOSTSyncros Duncan Dropper Post 2.5
31.6mm / S size 125mm / M & L size 150mm / XL size 170mm
SEATSyncros Tofino 1.5 Regular
Titanium rails
HEADSETAcros / 1.8"
ZS66 OD74 / integr. Cable
HUB (FRONT)Formula CL-811 / 15x110mm
HUB (REAR)Formula ECT-1481 / Boost 148x12mm
SPOKESStainless Black
RIMSSyncros MD30 / 32H / 30mm / Pin Joint
Tubeless ready
FRONT TIREMaxxis Dissector 29x2.6"
120TPI Foldable Bead
EXO+ / TR Tubeless ready
3C Maxx Terra
REAR TIREMaxxis Dissector 29x2.6"
120TPI Foldable Bead
EXO+ / TR Tubeless ready
3C Maxx Terra
LIGHTSBosch Light Cable pre-installed F&R
EXTRASRock Shox Fork Fender
Syncros eRIDE integrated light fender
APPROX WEIGHTS IN KG26.50
APPROX WEIGHTS IN LBS58.42
MAX. SYSTEM WEIGHT128 kg
The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
Sizes available: Medium, Large
