This bike is special order only
Maximum Range 22 miles / 35km
Recharge Time 5 hours
Maximum Assisted Speed 15.5mph / 25kmh
Motor Bafang 36V 250W motor
Motor Type Rear hub motor
Motor Torque 54Nm
Battery 238Wh (36V 6.6Ah)
Battery Type Integrated with USB charging function
Charger 3 pin UK plug
Display Handlebar mounted LED display, 3 level power assist & walk assist
Speed Sensor 12 point pedal sensor
Frame Alloy folding frame with integrated battery
Frame Size 13" (Folding)
Fork Hi-tensile steel
Headset 1" threaded
Handlebar Flat, 600mm wide
Stem Alloy telescopic folding stem
Grips Black ergo comfort grips
Gear Shifters Shimano Revoshift, 6 speed
Rear Derailleur Shimano RD-TZ500, 6 speed
Chain KMC Z7
Cassette/Freewheel Shimano 6 speed freewheel, 14-28T
Chainset 170mm crank, 52T chainring
Number of Gears 6
Bottom Bracket Cartidge type, 122.5mm
Pedals Folding pedals for improved storage
Brakes Mechanical disc brakes, 160mm rotors
Brake Levers Alloy lever including motor cut-off switch
Front Hub 36 hole, Alloy nutted
Rear Hub Bafang 36V 250W motor
Rims 20" double wall alloy rims with CNC sidewall
Tyres 20 x 1.75" city tyres
Saddle Comfort saddle
Seat Post 34mm x 55mm
Mudguards Full length, black steel
Kickstand Alloy centre mount
Pannier Rack Not included
Weight 19.5kg
